Jaylec - Push Button Switch Off/ Mom On 12 Volts 10 Amps
Jaylec Push Button Switch Off/Mom On 12/24 Volt 10amp.
2 Position - Off/Mom On- Single Pole - Single Throw- Protective Weather/Dust proof Rubber Cap Actuator.
Maximum Load: 10amp at 12 Volt- 5amp at 24 Volt.
On with actuator pressed- spring return to Off position.
Copper Contacts.
2 Screw terminals.
Mounting Stem: 6.95mm long with a M22 x 1 thread and 22.00mm diameter.
Suits panel thickness 1.52mm to 6.35mm.
1 year Warranty.
Dimensions:
56mm x 22mm.
| Specifications | |
| Voltage | 12 - 24 VOLT |
| Amps | 10 |
| Function | OFF / MOM ON |
| Number of Terminals | 2 |
| Number of Postions | 2 |
| Contact Configuration | SPST |
$4.79
Original: $13.70
-65%Jaylec - Push Button Switch Off/ Mom On 12 Volts 10 Amps—
$13.70
$4.79Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Jaylec Push Button Switch Off/Mom On 12/24 Volt 10amp.
2 Position - Off/Mom On- Single Pole - Single Throw- Protective Weather/Dust proof Rubber Cap Actuator.
Maximum Load: 10amp at 12 Volt- 5amp at 24 Volt.
On with actuator pressed- spring return to Off position.
Copper Contacts.
2 Screw terminals.
Mounting Stem: 6.95mm long with a M22 x 1 thread and 22.00mm diameter.
Suits panel thickness 1.52mm to 6.35mm.
1 year Warranty.
Dimensions:
56mm x 22mm.
| Specifications | |
| Voltage | 12 - 24 VOLT |
| Amps | 10 |
| Function | OFF / MOM ON |
| Number of Terminals | 2 |
| Number of Postions | 2 |
| Contact Configuration | SPST |
