Voltage: 12V
Kilowatt: 1.1kw
Number of Teeth: 9T
Pinion Diameter: 29mm
Rotation: CW
Pinion at Rest: 9mm
Flange Diameter: 74mm
Mount Hole Center to Center: 132mm
Mount Hole Diameter: M10- 11mm
Overall Length: 211mm
Oil Sealed
Series
Ground: NEGATIVE
Housing Index: FIXED
Weight (Kg)

Fitment information

Vehicles

• Toyota Corolla 2001 1.8L l4
• Toyota Corolla 2000 1.8L l4
• Toyota Corolla 1999 1.6L l4
• Toyota Corolla 1999 1.8L l4
• Toyota Corolla 1998 1.6L l4
• Toyota Corolla 1998 1.8L l4
• Toyota Corolla 1997 1.6L l4
• Toyota Corolla 1996 1.6L l4
• Toyota Corolla 1995 1.6L l4
• Toyota Corolla 1995 1.8L l4
• Toyota Corolla 1994 1.6L l4
• Toyota Corolla 1994 1.8L l4
• Toyota Corolla 1993 1.6L l4
• Toyota Corolla 1993 1.8L l4
• Toyota Corolla 1992 1.6L l4
• Toyota Corolla 1992 1.8L l4
• Toyota Corolla 1991 1.6L l4
• Toyota Corolla 1990 1.6L l4
• Toyota Corolla 1989 1.6L l4
• Toyota Corolla 1988 1.6L l4
• Toyota Corolla 1987 1.6L l4

Series

*E10*, *E11*, *E9*, AE101R

Chassis numbers

AE101, AE101*, AE102, AE102*, AE112, AE92, AE95

Engine codes

4A-F, 4A-FE, 7A-FE

Cross-reference parts

• 2810087213000
• 2810016041
• 2810016010
• 2810016071
• 2810016070
• 2810087213
• 2810016040
