Specifications
Voltage	12V
Kilowatt	1.4kW
Number of Teeth	10T
Pinion Diameter	28mm
Rotation	CW
Pinion at Rest	10mm
Flange Diameter	57mm
Mount Hole Center to Center	74mm
Mount Hole Diameter	10mm
Overall Length	226mm
Oil Sealed
Series
Ground	NEGATIVE
Housing Index	FIXED
Weight (Kg)

Fitment information

Vehicles

• Holden Berlina 2006 5.7L V8
• Holden Berlina 2005 5.7L V8
• Holden Berlina 2004 5.7L V8
• Holden Commodore 2006 5.7L V8
• Holden Commodore 2005 5.7L V8
• Holden Commodore 2004 5.7L V8
• Holden Commodore 2003 5.7L V8
• Holden Commodore 2002 5.7L V8
• Holden Commodore 2001 5.7L V8
• Holden Commodore 2000 5.7L V8
• Holden Commodore 1999 5.7L V8
• Holden Monaro 2005 5.7L V8
• Holden Monaro 2004 5.7L V8

Series

VT, VX, VY, VZ

Chassis numbers

VT, VX, VY, VZ

Engine codes

LS1, LS1 (GENIII)
