TAG Extreme Recovery Towbar Wiring Adaptor Solution for your GWM Cannon Alpha Cab Chassis (08/2024 - On)
The TAG Extreme Recovery (XR) Towbar and Wiring Adaptor Kit (TXRA26-K201) is engineered for the GWM Cannon Alpha Cab Chassis (Converted) models (08/2024 - On). This heavy-duty system offers a 3500kg tow capacity and includes two WLL 4500kg load-rated recovery points.
Kit Includes:
- TAG Extreme Recovery Towbar (TXRA26)
- 13-Pin Euro to 7-Pin Flat AU Adapter (UNT057)
TAG Extreme Recovery Towbar Features:
- Extreme Duty Reinforced Crossbar
- Two WLL 4500kg Load-Rated Recovery Points integrated into our 3-Piece Design side-arms with bevelled edges to suit soft-shackles.
- Flush chassis-mounted profile for maximum offroad clearance for improved departure angles.
- Highly durable, textured Extreme Duty Powder Coated Finish
- Dual top-mounted Trailer & Anderson Plug Mounts
- Class 4 Towbar - 50mm Square Hitch Receiver
- TAG Limited Lifetime Warranty
- Includes Zinc Tow Ball & Extreme Duty Hitch rated at 3500kg towing capacity / 350kg ball weight, Pin & Clip and D-Shackles
Wiring Adaptor Features (UNT057):
The UNT057 is a high-quality 13-Pin Euro to 7-Pin Flat AU Adapter designed for seamless compatibility with supported vehicles and towing systems.
- Plug & Play: Direct fit with no diagnostic coding required.
- Tow Mode Activation: Automatically adjusts vehicle systems when towing on compatible vehicles.
- Reverse Sensor Cut-Off: Enabled when used with compatible vehicles.
Important Note: For vehicles that activate “Tow Mode” automatically, it is recommended to only connect the UNT057 when towing.
Specifications:
- Towbar Class: Heavy Duty (4x4 Recovery)
- Towbar Capacity [kg]: 3500
- Static Load Capacity (Ball Weight) [kg]: 350
- Recovery Load-tested: 4500kg WLL
- Recovery Points: 2
- Hitch Type: 50mm Square Hitch Receiver
- Coating: Textured Powder Coated
- Exposure: Exposed
- Bumper Removed During Fitment: No
- Bumper Cut Out Required: No
Wiring & Fitting Details:
- Wiring Option: 13-Pin Euro to 7-Pin Flat AU Adapter (UNT057)
- Diagnostic Coding: No
- Towbar Fitting Time [min.]: 40 (TXRA26)
- Wiring Fitting Time [min.]: 2 (UNT057)
Please Note: A towbar is a safety critical item and not always a straightforward fitment due to vehicle manufacturing variation. We strongly recommend you get your towbar and wiring harness installed by a professional towbar or vehicle accessory fitting workshop.
Important Information
- The image shown may not reflect the actual product
- Shipping times may vary depending on destination and stock availability
Vehicle Applications for GWM Cannon Alpha Cab Chassis (08/2024 - On)
| Make | Model | Year Range | Body Type | Series | Engine Details | Variant | Drivetrain |
|---|---|---|---|---|---|---|---|
| GWM Cannon Alpha Cab Chassis (08/2024 - on) | |||||||
| GWM | Cannon Alpha | 05/2024 - - | Cab Chassis (Converted) | P05 | GW4D24 | 2.4L | Diesel | Lux,Ultra | Automatic 4WD |
